Component manuals – Magnum Venus Plastech Quick Shot User Manual
Page 26
Quick Shot Operations Manual
Rev. 03/2013
Page | 26
Component Manuals:
Pump / Fluid Section Manual:
The Quick Shot comes standard with the VPRO-45110-QS Fluid Section / Pump
assembly. For detailed repair instructions see the manual “VPRO-45110 Series Pump
Manual”
Catalyst Pump Manual:
The Quick Shot comes standard with the CPC-2000-RV-INT Catalyst Pump. For
detailed repair instructions see the manual “PCP-2000 Catalyst Pump Manual – Low
Range”
