Quick Shot Operations Manual
Rev. 03/2013 Page | 16
Introduction:
A state-of-the-art, easy-to-use pail dispensing system designed for the fiber
reinforced composites industry.
MVP’s Quick Shot Pail Dispenser features an 11:1 power ratio positive displacement
fluid pump, capable of delivering up to 4 – 8 lbs. per minute. Slaved to the resin pump,
the catalyst pump can meter measured amounts of MEKP into the resin varying from
1% to 2.5% of the volume of the resin.
The Quick Shot is very simple to operate. Resin and catalyst can be mixed by hand or
with an optional air-driven pail mixer to disperse the catalyst evenly throughout the resin.
Operators can achieve accurately measured, evenly mixed catalyst and resin quickly
and easily. Because two materials are pumped separately into the pail, there are no
accumulators to charge and no gun to flush.
BASIC UNIT FEATURES:
Pro Series™ Resin Pump
Catalyst Pump
Regulator/Filter Combination Unit with gauge
Catalyst Inline Relief Check Valve
Parallel Ball Valve Assembly (for dispensing resin & catalyst)
OPTIONAL UNIT FEATURES:
Optional Air-Driven Hand Mixer
Optional Wall Mount Configuration
CONTENTS:
Standard unit marking on box:
1.
VPRO-45110 Resin Pump Assembly
2. PCP-1000-RV-INT Catalyst Pump Assembly
3. 85690-1 Dual Ball Valve Assembly
4. CJ-2000-4-RSP 2 Gallon Catalyst Jug
5. RV-1000-500 Catalyst Relief Valve – 500psi
6. HSA-1000 Assy. - Wand 55 Gal
7. 85693-1 Pump Mount Column (Base Mount unit only)
8. 62640-3 Base Plate (Base Mount unit only)
9. 85681-1 Bracket Extension - Valve Mount (Base Mount unit only)
10. 05812 Regulator/Filter Combo with Gauge
11. 06414 Gauge - 160 PSI - 2" Face
12. 85730-1 Cat Jug Bracket
13. 85723-1 Pump Mount Bracket
Check contents of box before installation.
