1- NOT USED
2- SCALED OUTPUT O.C.
3- ANALOG OUTPUT (SINK)
4- INPUT A (PULSE/ANALOG)
5- RESET INPUT
6- NOT USED
7- NOT USED
8- NOT USED
9- NOT USED
10- NOT USED
11- GROUND (-DC)
12- GROUND (-DC) INPUT COMMON
13- +12 VDC OUT
14- +DC POWER IN
15- ISOLATED -12VDC
16- ISOLATED +12VDC
17- AC IN
18- AC IN
19- PRESET B OPEN COLLECTOR
20- PRESET A OPEN COLLECTOR
R1- N.O
R2- N.C.
A
R3- COMMON
R4- N.O
R5- N.C.
B
R6- COMMON
COUNTER
K-FACTOR __ __ __ __ __ __ __ __
Reset to 0
Set to Preset
DECimal LOCation (0-8)
8 7 6 5 4 3 2 1 0
none
RATEMETER
K-FACTOR __ __ __ __ __ __ __ __
WINDOW (02-24) __ __
SIGnificant FIGures (1-6) __ __
WEIGHT (00-99) __ __
AnaLoG OUTput RaTe CouNT
SET LOW rate 4mA __ __ __ __ __ __ __ __
SET HIGH rate 20mA __ __ __ __ __ __ __ __
OUT FREQuency
20000
2000
200
10
OUTCARD
UNIT (00-15) __ __
ParalleL or SERial
(RS422M)
BAUDRATE PARITY
300 SPACE
600 EVEN
1200 ODD
2400 MARK
4800
9600
PRE A PRE B RATE/TOTAL MENU
A B C D
1 2 3
5 4 6
8 7 9
0 ENT CLR
WORKSHEET
MODEL #
SERIAL #
UNIT #
LOCKOUT CODE __ __ __ __
PR-LCK PR-UNLK
PRESET A __ __ __ __ __ __ __ __
PRESET B __ __ __ __ __ __ __ __
RELAY Open Collector
A TOTAL
A GRand TOTal
A RATE
DURation of A (0.0-9.9) __ . __
B TOTAL
B GRand TOTal
B RATE
DURation of B (0.0-9.9) __ . __
2
