Liquid Controls DMS Installation - Manual (Page 18)

18
bIll of MaTerIals
optional Items (not shown)
description Part number
DMS Power Cable 81973
DMS Printer Power Cable 81233
DMS Lap Pad E4040
USB Memory Device 81975
Mounting Bracket Kit 82170
Item description Part number
1 Base Enclosure 81953
2 DB9 Cover Plate (2) 81956
3 Screw, #4-40 x .375 (12) 08114
4 Self Locking Nut (8) 07753
5 Interface Board Assembly 81960
6 Screw, #6-32 x .375 (8) 08117
7 Standoff, .75” (3) 08213
8 Standoff, 1.0” (4) 08214
15
PC/104 Computer Board
(81955) with CF Card (81970)
81958
18 Rear Panel Enclosure 81954
19 Screw, #10-32 x .38 (2) 08119
20 Screw, #10-32 x .38 (4) 08120
21 DB25 Cover Plate (2) 81957
29 Screw, #6-32 x .25 (8) 08211
