Input+Scaling tab. Works only with the Custom ASCII protocol, not the Modbus protocol,
since a meter cannot listen to commands while in the Rmt Dsply C display type.

Executing a Main Menu > Counter > Put Setup command downloads the setup information
into the meter, including the Rmt Dsply C display mode if selected. Do not execute a Main
Menu > Counter > Get Setup command if you have placed the meter into the Rmt Dsply C
mode, since normal meter communications cannot occur in that mode. Our Instrument
Setup Software will then reset the meter to Rmt Dsply A so that it can retrieve the setup
information from the meter.

For more information on serial communications, please download our Series 2 Serial Com-
munications Manual (for Custom ASCII Protocol) and our Series 2 Modbus Communications
Manual (for Modbus Protocol).

For Control Inputs, select the desired action of grounding Control Input 1, Control Input 2,
and both Control Inputs 1 and 2.

Meter Reset is a master reset like removing and reapplying power.

Function Reset resets latched alarms.

Alarm Active allows external control of relays, as opposed to using normal setpoint

operation.

Display Blanking blanks the meter display.

Enable Tare enables a meter tare function and enters the current reading as a value to

be subtracted as a tare value.

Tare if Enabled subtracts the tare value from the current reading.

Ignore the following selections, which do not apply to remote display operation: Peak,
Valley, External Gate, Meter Hold, Total A Reset, Total B Reset.
