SELECTED FRONT PANEL SETUP ITEMS FOR SERIAL INPUT METER (not consecutive)

If the MENU

key does not work, see Section 9 “Enabling & Locking Out Menu Items.”

Press
Menu

Press Digit
Select Key

Press Value Select
Key

SEtuP

Setup

_000_0

Control inputs 1 and 2

F

1 = Tare, 2 = Tare enable

Control input 2 must be at 0V or grounded for
Tare to operate.

ConFiG

Configu-
ration

__0000

Display mode


Note: Remote modes
S (selection 7) and C
(selection C) are used
for most applications.

6

Remote display (H, K, L commands)

7

Single-value remote display

8

Show 1

st

string value, connected to a counter

9

Show 2

nd

string value, connected to a counter

A

Show 3

rd

string value, connected to a counter

B

Show 4

th

string value, connected to a counter

C

Custom Start, Stop, Skip, Show characters

.

ti_Out

.

Time-out

_000.00 _000.00 _000.00
_000.00 _000.00

Select digit to flash.

Select

0

thru

9

for flashing digit to set time-out in

seconds. Decimal point location is fixed for 10 ms
resolution.

.

SEr 1

.

__000U

Baud rate

Fixed parameters:
No parity, 8 data bits,
1 stop bit

0

300 baud

1

600 baud

2

1200 baud

3

2400 baud

4

4800 baud

5

9600 baud

6

19200 baud

.

SEr 2

.

__0000U

Meter address

Select

0

thru

F

for addresses 1 thru 15. Select

0.

thru

F.

(with decimal point) for addresses 16 thru 31.

.

SEr 3

.

_00000U

RS485

0

Full duplex

1

Half duplex

___000U

Serial protocol

0

Custom ASCII

1

Modbus RTU

2

Modbus ASCII

SEr 4

.

___000U

Parity

0

None

1

Odd

2

Even

_

Addr

___000 __000 ___000

Modbus address

__158

Select

0

through

9

for flashing digit. Address

range is 1 to 247.
