Laurel Electronics LAUREATE SERIES 2 SERIAL INPUT METER & REMOTE DISPLAY User Manual
Page 21
21
KEYSTROKES FOR SETUP OF DUAL ANALOG OUTPUT BOARD
If the MENU
key does not work, see Section 9 “Enabling & Locking Out Menu Items.”
Press Menu
Key
Press Digit Select
Key
Press Value Select
Key
0000
Scaling of analog output 2
0
0-20 mA current output
1
0-10V voltage output
2
4-20 mA current output
0000
Source of analog output 2
3
Must be set to Item #3.
0000
Scaling of analog output 1
0
0-20 mA current output
1
0-10V voltage output
2
4-20 mA current output
An_SEt
Analog Output Setup.
Press
until AnSEt is
displayed.
0000
Source of analog output 1
3
Must be set to Item #3.
An_Lo1
Low displayed value for
0V, 0 mA, or 4 mA output
0.00000 0.00000 0.00000
0.00000 0.00000 0.00000
Select digit to flash
Select
0
thru
9
for flashing digit.
An_Hi1
High displayed value for
10V or 20 mA output
0.00000 0.00000 0.00000
0.00000 0.00000 0.00000
Select digit to flash
Select
0
thru
9
for flashing digit.
dEC.Pt1
selection.
An_Lo2
Low displayed value for
0V, 0 mA, or 4 mA output
0.00000 0.00000 0.00000
0.00000 0.00000 0.00000
Select digit to flash
Select
0
thru
9
for flashing digit.
An_Hi2
High displayed value for
10V or 20 mA output
0.00000 0.00000 0.00000
0.00000 0.00000 0.00000
Select digit to flash
Select
0
thru
9
for flashing digit.
