4
INTRODUCTION
The IS system is a commercial and security video intercom system especially designed for applications in facilities such as offi ce
buildings, factories, schools, hospitals, and prisons. Installed separately from conventional general-purpose internal communications
systems, the IS system can be used as a video door entry system, emergency announcement system, rescue assistance system,
urgent call system, public announcement system, and access control system.
About this manual
This manual describes how to use a network direct system (without an IP control unit) only. For a standard (IP) system (including one
or more IP control units), refer to the “OPERATION MANUAL” for the standard (IP) system.
Notice the following:
Master stations and door stations that can be used in a network direct system are IP units (IS-IPMV, IS-IPDV, IS-IPDVF and IS- •
SOFT) only.
You can also call, page or communicate with a remote site. This manual also describes operations for calling, paging and communicating •
with a network direct system in a remote site. So note that the term “a remote site” used in this manual means “a network direct system
in a remote site”. For a standard (IP) system in a remote site, refer to the “OPERATION MANUAL” for the standard (IP) system.
PRECAUTIONS
General Prohibitions Prohibition to Dismantle the Unit Prohibition on Subjecting the Unit to Water
General Precautions
WARNING
Negligence could result in death or serious injury.
1. Do not dismantle or alter the unit. Fire or electric shock could
result.
2. Keep the unit away from water or any other liquid.
Fire or electric shock could result.
3. High voltage is present internally. Do not open the case.
Electric shock could result.
4. Do not connect any non-specifi ed power source to the +, -
terminals. Also, do not install two power supplies in parallel to a
single input. Fire or damage to the unit could result.
5. Do not connect any terminal on the unit to an AC power line.
Fire or electric shock could result.
6. Do not use power supply with a voltage other than specifi ed.
Fire or electric shock could result.
7. Do not put any metal or fl ammable material into the unit
through the openings. Fire, electric shock, or unit trouble could
result.
8. The unit is not explosion-proof. Do not install or use near gases
or fl ammable materials. Fire or explosion could result.
9. Existing wiring such as chime wiring, etc. may contain high
voltage AC electricity. Damage to the unit or electric shock
could result. Wiring and installation should be done by a
qualifi ed technician.
CAUTION
Negligence could result in injury to people or damage to property.
1. Do not install or make any wire terminations while power
supply is plugged in. It can cause electrical shock or damage to
the unit.
2. When mounting the unit on a wall, install the unit in a
convenient location, but not where it could be jarred or
bumped. Injury could result.
3. Before turning on power, make sure wires are not crossed or
shorted. If not, fi re or electric shock could result.
4. For power supply, use Aiphone power supply model or model
specifi ed for use with system. If non-specifi ed product is used,
fi re or malfunction could result.
5. On products with ground terminals, connect to an earth ground.
Fire or malfunction could result.
6. Do not put anything on the unit or cover the unit with cloth, etc.
Fire or unit trouble could result.
7. Do not install the unit in any of the following locations. Fire,
electric shock, or unit trouble could result.
Places under direct sunlight or places near heating *
equipment that varies in temperature.
Places subject to dust, oil, chemicals, hydrogen sulfi de (hot
*
spring).
Places subject to moisture and humidity extremes, such as
*
bathrooms, cellars, greenhouses, etc.
Places where the temperature is quite low, such as inside a
*
refrigerated area or in front of an air conditioner.
Places subject to steam or smoke (near heating or cooking
*
surfaces).
Where noise generating devices such as dimmer switches or
*
inverter electrical appliances are closeby.
Locations subject to frequent vibration or impact.
*
8. Do not put high pressure on the LCD. If fractured, injury could
result.
9. If the LCD is punctured, do not allow contact with the liquid
crystal inside. Infl ammation could result. If necessary, gargle
your mouth and clean your eyes or skin with clear water for at
least 15 minutes, and consult your doctor.
10. Do not use the handset when you perform a call test or check
the volume, otherwise it may cause damage to your ear. Be
sure to use the built-in speaker.
11. Be sure to perform a call test or check the volume with the
handset on the hook. If you operate the hook switch with the
handset on your ear, a sudden call etc. may arrive causing
damage to your ear.
