5.2 Control Wiring
Important:
Controls must be installed
a minimum of 10-feet from the gate or
installed in such a way that the person
using the control cannot come in
contact with the gate or gate operator.
Gate Tracker
-
DoorKing Access Control System (Model 1833, 1835, 1837 or 1838) tracker
system can be connected. This system can keep track of gate operator cycle count, shorted
inputs, loop detector problems, any forced entry attempts, if the gate has struck anything during
the open or close cycle, power interruptions, etc. For more detailed information refer to the
Tracker Installation and Wiring Manual, DoorKing P/N 2351-010.
Terminal #2 (Full open) required only if the tracker board will activate the gate operator. Refer to
the manual 2351-065 for detailed information.
Power is limited
to 250 mamps.
SW 1, Switch 3 Must be ON.
Power (24-Volt DC) and logic
output. Power is shut off .5 sec.
prior to gate starting and remains
off while gate is opening and in
the open position.
SW 2, switch 2 ON.
White
24 Volt
Com
1 amp max.
Stand-Alone
Key Switch
#4 - Safety
Opening
Device
Stand-Alone
Keypad
Stand-Alone
Card Reader
Telephone
Entry
“REVERSE” Closing-Direction Photo Sensors
Note: All stand-alone
and telephone entry devices must
use a separate power source.
Remote Alarm Reset Station
(DKS P/N 1404-080) MUST be mounted
in the line-of-sight of the gate operator.
SW 1, switch 5:
After photo sensor
beam gets obstructed:
OFF- Reverses gate.
See page 24 for more
information.
Radio
Open
Access
Device
Open
Safety
Open
3-Wire Radio
Receiver
Red
Blue
Alarm
Alarm
Reset
SW 1
1
ON
2
3
4
5
6
7
8
SW 1
1
ON
2
3
4
5
6
7
8
SW 2
1
ON
2
3
4
Com
24 V
olt
Relay
3-Pin
Remote
Terminal
#5 - Access Control
Devices
Magnetic Lock
Quad Bo
x
Shown
#4 Normally Open
#5 Normally Open
#6 Normally Open
#9 Normally Close
1
2
3
Orange
Brown
White
