3.3 Limit Sensors

Loosen set screw to
adjust the limit
sensor.

Magnetic

Open

Limit Sensor

Magnetic

Close

Limit Sensor

Magnetic Sensor
Activator

Magnetic sensor activator
must be directly above the
limit sensor to activate it.

The hub must not slip
during operation. Tighten
bolt to stop any slipping.

CAUTION

DO NOT REMOVE HUB!

OPEN SENSOR

CLOSE SENSOR

P2

P8

EXIT
LOOP

Limit

Sensors

Plug

Not Used

Open

Close

Primary

Limit

Sensors

Secondary

Limit

Sensors

Close

Open

OOP

P

e

OP

P

e

OP

P

e

OP

P

e

OP

P

OP

P

OP

P

OP

P

P

e

e

e

e

P2

Switch 1 “OFF”

SW 1

1

ON

2

3

4

5

6

7

8

SW 1

1

ON

2

3

4

5

6

7

8

PRIMARY

Operator DIP Switch OPENING Direction

SW 1

1

ON

2

3

4

5

6

7

8

SW 1

1

ON

2

3

4

5

6

7

8

SECONDARY

Operator DIP Switch OPENING Direction

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

1

ON

SW 1

2

3

4

1

ON

SW 2

REVERSE
LOOP

P2

P8

EXIT
LOOP

SELF
TEST

NC

TIME
DELAY

NO

REV SENSE
PRIMARY

REV SENSE
SECONDARY

1

2

3

4

5

6

7

8

9

13

12

11

10

14

15

16

17

18

19

20

2

3

4

5

6

7

8

4405-010

Note: If P2 plug is not connected
to the circuit board and AC power
is turned on, alarm will sound
and operator will NOT function.

Operator Opens
Counter-clockwise

Switch 1 “ON”

Operator Opens
Clockwise

Switch 2 “OFF”

Operator Opens
Counter-clockwise

Switch 2 “ON”

Operator Opens
Clockwise

Dual Gate Operators Note: SW 1, switch 2 will be set the opposite
of SW 1, switch 1 (e.g. If switch 1 is OFF, then switch 2 will be ON).

Limit Sensor LEDs

Important Limit Sensor Adjustment Note:

It is very important NOT to cycle the gate operator
before the limit sensors are in the correct position or
it could cause damage to the gate and operator.

ONLY turn ON AC power. Manually release the gate
operator hub with the release tool (See page 31).
Physically move the gate to the desired open
position. Loosen the set screw on the OPEN limit
sensor and slowly slide it under the magnetic sensor
activator until the OPEN limit Sensor LED lights up
on the circuit board. Tighten the set screw and
repeat this process for the close gate position.
Secure the hub with the release tool and cycle the
operator a few times and readjust if necessary.

Release T

ool
