6550-065-A-4-12 11
Standard Installation
Operator Installation
1.3 Type of Installations
Recommended for gates up to 25 feet opening 90°.
Concrete Pad
90°
90°
Alternate Installation
Concrete Pad Location
Concrete Pad Location
Operator Installation
Recommended for gates up to 18 feet opening 90°.
Concrete Pad
1
2
24”
36”
17”
46” 14”
44”
35”
38.5”
30”
42” 14”
38”
35”
35”
30”
2”
24”
36”
17”
2”
Space Gained from Alternate Installation
12”
12”
