6550-065-A-4-12

15

2.1 High Voltage Wire Runs

2.2 High Voltage Terminal Connections

The distance shown in the chart is measured in Feet from the operator to the power source. If power wiring is greater than the
maximum distance shown, it is recommended that a service feeder be installed. When large gauge wire is used, a separate
junction box must be installed for the operator connection. The wire table is based on stranded copper wire. The wire run
calculations are based on a power source with a 3% voltage drop on the power line, plus an additional 10% reduction in
distance to allow for other losses in the system.

“Optional” 3.3 Amp Heater Installation Note: When installing the heater(s), refer to the “high voltage AC power wire size and
distance requirements”
table on the instruction sheet with the heater kit (P/N 6550-480) for AC power wire run requirements.

This table illustrates the high voltage wire size and distance requirements for a single operator.

Reduce the wire distance in half for a primary/secondary dual gate operator application

Model

Type

Voltage

Required

Amps

Required

Wire Size / Distance in Feet

12 AWG

10 AWG

8 AWG

6 AWG

Never

run low voltage rated wire insulation in the same conduit as high voltage rated wire insulation.

100
395

1550

9.7
4.9
2.5

115

208/230

460

162
630

2480

270

1055
4140

405

1580
6210

6550 1 HP

6550 1 HP

6550 1 HP

Chassis

Ground

Neutral

115 V

A

C

115 VAC

208/230/460 V

A

C

208/230/460 V

A

C

115 V

A

C Neu

115 V

A

C Neu

115 V

A

C Hot

Route incoming high voltage power through conduit and

into the operator as shown.

Be sure wiring is installed in accordance with local codes.

Be sure to color code all wiring.

It is recommended that a surge suppressor be installed on

the high voltage power lines to help protect the operator
and circuit board from surges and power fluctuations.

Secondary operator in a dual operator application gets AC

power through the 8-wire interconnection cable that
connects the 2 operators together. See next page.

208 / 230 / 460 VAC

Chassis

Ground

DANGER

HIGH VOLTAGE!

DO NOT

cycle the operator without the OPEN and CLOSE limit sensors in their specific open

and close positions.

The limit sensors or the AC power switch are the ONLY ways to stop the operator once

an open cycle has started. This could cause damage to the gate and/or operator if the gate opens too far!

High Voltage

AC Input Wire

High Voltage

AC Input Wire

Hot

Neu

PU

SH

TO

O

PE

RAT

E

tec

hni

cia

n u

se

on

ly

High Voltage
AC Input Wire

High
Voltage
Conduit

Use only two legs of the
incoming 3-phase power.

Output

Input
