Parts list – Kolpin 86360 - ATV SPREADER User Manual
Page 7
PARTS LIST
REF#
DESCRIPTION
QTY
1
Rain Cover
1
2
Electric Motor Lid
1
3
Electric Motor
1
4
Electric Motor Cover
1
5
Tie
1
6
lock Nut M6
2
7
Motor Support
1
8
Hopper Assembly
1
9
Flat Washer Ø6
4
10
Hex Bolt M6x16
2
11
Wire Clamp
1
12
Adjustment Plate A
1
13
Rivet Ø5x12
4
14
Wood Screw M5x35
4
15
Center Spacer
1
16
Turning Plate
1
17
Adjustment Plate B
1
18
Round Head Screw M4x20
1
19
Round Head Screw M6x45
1
20
Carriage Bolt M6x25
1
21
Frame
2
22
Gauge Assembly
1
23
Spacer
1
24
Wing Nut M6
2
25
Handle
1
26
Wire Adjustment Clip
1
27
Wood Screw M4x18
1
28
Adjustment Wire
1
29
Round Head Screw M6x16
2
30
Lock Washer Ø6
2
31
Wire Assembly
1
32
Hex Nut M6
8
33
Press Plate
4
34
J-Bolt
8
35
Round Head Screw M5x12
2
36
Wire Clamp Press Plate
1
37
Lock Nut M5
2
