UNPACKING
INSTRUCTIONS
When unpacking the tools:
1-
Carefully remove the tool and accessories from the box.
2-
Make sure that all items listed in the packing list are included.
3-
Inspect the tool carefully to make sure no breakage or damage
occurred during shipping.
4-
Do not discard the packing material until you have carefully inspected and satisfactorily operated the
tool.
1- Attach frames to hopper as shown
using M5x35 Wood Screws (#14).
2- Position the rate control assembly to
either frame rail based on if the
spreader is mounted to the front or the
rear rack. If mounted on front rack the
control should be positioned to the left
rail, if mounted on the rear rack the
control should be positioned on the
right rail.
WARNING: If any parts are
missing do not operate the tool
until the missing parts are
replaced. Failure to do so could
result
in
possible
serious
personal injury.
ASSEMBLY
