60
Maintenance
9.3.3 Actuator verification
Manual displacement
Move to the home
position (top)
Move up
Stop (only applicable
when moving to the
home position)
Move down
Press on the icons displayed left to perform the required operation on
the piercing assembly.
The current position is displayed on the left side of the screen as the
assembly moves either up or down.
It is advisable to check the displacement process using the two
different speed settings by pressing on these two buttons (tortoise for
slow and hare for fast).
Press on the icon with the down arrow to lower the needle without
moving the piercing assembly.
Press on the icon with the up arrow to raise the needle back into the
home position.
Ultrasound ON/OFF
Switch between having the ultrasound system on or off.
Important Note:
Before turning ON, remove any pierced packages from the package holder to avoid any
liquid spillage.
With some water in the base of the package holder, test the system is working by moving your finger
across the base of the package holder and toggling the switch between ON and OFF. You should sense
a noticeable difference.
Lasers ON/OFF
Switch between having the lasers on or off.
Test the system is working by toggling the switch to ON and you should see the two red laser beams
intersecting on the package holder. Toggle the switch back to OFF and the laser beams should
disappear.
