Hach-Lange ORBISPHERE 6110 User Manual - Manual (Page 24)

22
Installation
3.5 Additional installation information
3.5.1 Microsoft ActiveSync® configuration
This software must be installed on your PC when connecting to the instrument via the USB
client connector (No. 5 in
Figure 3 on page 16 ). The latest version of ActiveSync® is available
as a free download from www.microsoft.com
Once successfully installed, ActiveSync® will
start automatically each time the instrument is
connected to the PC.
Note: By default ActiveSync® proposes to set up a
partnership with the instrument. This is not
required, so make sure this is set to NO (as
illustrated left) before continuing.
The ActiveSync® screen is then displayed
and an icon will appear in the taskbar at the
bottom of your screen.
When active the icon in the taskbar is colored green (as illustrated top left)
and when inactive, the icon is still visible but greyed out (as illustrated
bottom left).
