7.2 Diagnostic measurement and results views
These views are essentially used for troubleshooting purposes by Hach Lange service
technicians, therefore no detailed explanation of the data displayed is given in this manual.
7.2.1 Measurement view
As the measurement process executes, the measurement details are displayed down the left
side of the screen. The first line of the display shows the current stage in the process. The right
side of the screen gives additional textual information.
7.2.2 Results view
The following screen is displayed on completion of the measurement process:
Note:
If the Stored measured sensor values box at the bottom of the screen is checked, the values are
recorded in the results file (and as raw data) but with pre-defined units. These units cannot be changed by
the user.
