99

Plumbing and Connection Options

Figure 38 Option 9a setup

1

FILTRAX 1

5

FILTRAX 2 heated hose

9

FILTRAX 1 sample line

2

FILTRAX 2

6

FILTRAX 1 heated hose

10 Overflow vessel 1

3

Seal plug #1

7

Drain tube: Feed to a physically
lower drain (maximum. 2 m/6.5 ft)

11 Overflow vessel 2

4

Seal plug #3

8

FILTRAX 2 sample tube
