IOM-9540R 15
NOTES
1. Reference Section III.D. Existing Control Valve
Modifications, paragraphs 1. and 2.
2. Remove positioner unit (101) by removing four
socket cap screw (33).
3. Remove range spring (102).
4. Remove both machine screws (37).
REPAIR PARTS KITS
Kit A: Includes gaskets, O-rings and small parts.
Order P/N 295-08-5-07410-00
Kit B: Replacement pneumatic amplifier.
Order P/N 653-75-5-09542-00
APPENDIX A
Removal of Model 9000R P/P Positioner
5. Remove feedback pivot link shaft (74), both spacers
(109), and feedback linkage assembly (73).
6. Install new cover plate (22), re-using socket cap
screws (33).
7. Re-install both machine screws (37).
8. Discard unused parts at user’s discretion.
