ST100 Series Profibus PA
Fluid Components International LLC
25
CLASSIC DIAGNOSIS DEFINITIONS
Classic DIAGNOSIS Mnemonic
Description
DIA_HW_ELECTR
Hardware failure of the electronic
DIA_HW_MECH
Hardware failure mechanics
DIA_TEMP_MOTOR
Motor- temperature too high
DIA_TEMP_ELECTR
Electronic temperature too high
DIA_MEM_CHKSUM
Memory error
DIA_MEASUREMENT
Failure in measurement
DIA_NOT_INIT
Device not initialized (No self calibration)
DIA_INIT_ERR
Self calibration failed
DIA_ZERO_ERR
Zero point error (limit position)
DIA_SUPPLY
Power supply failed (electrical, pneumatic)
DIA_CONF_INVAL
Configuration not valid
DIA_MAINTENANCE
Maintenance required
DIA_CHARACT
Characterization invalid
ST100 PROFIBUS PA (CONDENSED) DIAGNOSIS TABLE
PROFIBUS PA
DIAG_ EXT
PROFIBUS PA Condensed DIAG FCI Fault Type
PROFIBUS PA Status
# 0.0
DIA_MAINTENANCE_ALARM
F
BAD (4): ALL
# 0-1
NF
# 0-2
NF
# 0-3
DIA_MAINTENANCE_ALARM
F
BAD (4): ALL
# 0-4
NF
# 0-5
DIA_MAINTENANCE_ALARM
F
BAD (4): ALL
# 0-6
DIA_MAINTENANCE
NF
GOOD (1): ALL
# 0-7
NF
# 1-0
NF
# 1-1
NF
# 1-2
NF
# 1-3
NF
# 1-4
NF
# 1-5
DIA_MAINTENANCE_ALARM
F
BAD (4): ALL
# 1-6
NF
# 1-7
DIA_INV_PRO_COND
UNCERTAIN (5) 0, 2, 4
