ST100 Series Profibus PA
Fluid Components International LLC 9
Pressure Transducer Block Parameters
In some models the ST100 is equipped with a pressure transducer. This block describes the variable and parameters associated with the process
pressure measurement.
REL. INDEX PARAMETER SLOT INDEX DATA TYPE (LENGTH) STORE SIZE READ/WRITE
8 SENSOR_VALUE 8 24 FLOAT S 4 RW
9 SENSOR_HI_LIM 8 25 FLOAT N 4 RW
10 SENSOR_LO_LIM 8 26 FLOAT N 4 RW
11 CAL_POINT_HI 8 27 FLOAT S 4 RW
12 CAL_POINT_LO 8 28 FLOAT S 4 RW
13 CAL_MIN_SPAN 8 29 FLOAT N 4 RW
14 SENSOR_UNIT 8 30 UNSIGNED 16 S 2 RW
15 TRIMMED_VALUE 8 31 101(DS-33) D 5 R
16 SENSOR_TYPE 8 32 UNSIGNED 16 2 N R
17 SENSOR_SERIAL_NUMBER 8 33 UNSIGNED 32 4 N R
18 PRIMARY_VALUE 8 34 101 (DS-33) 5 D R
19 PRIMARY_VALUE_UNIT 8 35 UNSIGNED 16 2 S RW
20 PRIMARY_VALUE_TYPE 8 36 UNSIGNED 8 1 S RW
21 - 32 NOT USED 8 37-48
33 LIN_TYPE 8 49 UNSIGNED 8 1 S RW
FCI Internal TOTALIZER Transducer Block Parameters
The ST100 has the totalizer function built in. This function is made available through the PROFIBUS PA protocol in addition to providing the
PROFIBUS PA profile TOTALIZER. When needing a TOTALIZER function, FCI recommends the use of this TOTALIZER function.
REL. INDEX PARAMETER SLOT INDEX DATA TYPE (LENGTH) STORE SIZE READ/WRITE
8 TOTALIZER_STATE 9 24 UNSIGNED 8 D 1 RW
9 TOTALIZER_VALUE 9 25 FLOAT D 4 R
10 TOTALIZER_DYNAMIC_VALUE 9 26 101(DS33) D 5 R
11 TOTALIZER_UNIT_CODE 9 27 UNSIGNED 8 D 1 R
