ST100 Series Profibus PA
12 Fluid Components International LLC
Pressure Analog Input (AI) Block
The instruments equipped with a pressure sensor will make use of the Pressure AI block. This block gets its input from the Pressure transducer Block.
REL. INDEX PARAMETER SLOT INDEX DATA TYPE (LENGTH) STORE SIZE READ/WRITE
1 ST_REV 3 17 UNSIGNED16 N 2 R
2 TAG_DESC 3 18 OCTETSTRING S 32 RW
3 STRATEGY 3 19 UNSIGNED16 S 2 RW
4 ALERT_KEY 3 20 UNSIGNED 8 S 1 RW
5 TARGET_MODE 3 21 UNSIGNED 8 S 1 RW
6 MODE_BLK 3 22 DS-37 S 3 R
7 ALARM_SUM 3 23 DS-42 D 8 R
8 BATCH 3 24 DS-67 S 10 RW
10 OUT (PRESS.) 3 26 DS-33 D 5 R
11 PV_SCALE 3 27 FLOAT S 8 R/W
12 OUT_SCALE 3 28 DS36 S 11 R/W
13 LIN_TYPE 3 29 UNSIGNED 8 S 1 R/W
14 CHANNEL 3 30 UNSIGNED16 S 2 R/W
16 PV_FTIME 3 32 FLOAT S 4 R/W
17 FSAFE_TYPE 3 33 UNSIGNED 8 S 1 R/W
18 FSAFE_VALUE 3 34 FLOAT S 4 R/W
19 ALARM_HYS 3 35 FLOAT S 4 R/W
21 HI_HI_LIM 3 37 FLOAT S 4 R/W
23 HI_LIM 3 39 FLOAT S 4 R/W
25 LO_LIM 3 41 FLOAT S 4 R/W
27 LO_LO_LIM 3 43 FLOAT S 4 R/W
30 HI_HI_ALM 3 46 DS-39 D 16 R
31 HI_ALM 3 47 DS-39 D 16 R
32 LO_ALM 3 48 DS-39 D 16 R
33 LO_LO_ALM 3 49 DS-39 D 16 R
34 SIMULATE 3 50 DS50 S 6 R/W
35 OUT_UNIT_TEXT 3 51 OCTETSTRING S 16 R/W
