Temperature Analog Input (AI) Block
The Temperature AI block is the secondary parameter of the ST100 instrument. This block gets its input from the Temperature Transducer Block.
REL. INDEX PARAMETER SLOT INDEX DATA TYPE (LENGTH) STORE SIZE READ/WRITE
1 ST_REV 2 17 UNSIGNED16 N 2 R
2 TAG_DESC 2 18 OCTETSTRING S 32 RW
3 STRATEGY 2 19 UNSIGNED16 S 2 RW
4 ALERT_KEY 2 20 UNSIGNED 8 S 1 RW
5 TARGET_MODE 2 21 UNSIGNED 8 S 1 RW
6 MODE_BLK 2 22 DS-37 S 3 R
7 ALARM_SUM 2 23 DS-42 D 8 R
8 BATCH 2 24 DS-67 S 10 RW
10 OUT (TEMP.) 2 26 DS-33 D 5 R
11 PV_SCALE 2 27 FLOAT S 8 R/W
12 OUT_SCALE 2 28 DS36 S 11 R/W
13 LIN_TYPE 2 29 UNSIGNED 8 S 1 R/W
14 CHANNEL 2 30 UNSIGNED16 S 2 R/W
16 PV_FTIME 2 32 FLOAT S 4 R/W
17 FSAFE_TYPE 2 33 UNSIGNED 8 S 1 R/W
18 FSAFE_VALUE 2 34 FLOAT S 4 R/W
19 ALARM_HYS 2 35 FLOAT S 4 R/W
21 HI_HI_LIM 2 37 FLOAT S 4 R/W
23 HI_LIM 2 39 FLOAT S 4 R/W
25 LO_LIM 2 41 FLOAT S 4 R/W
27 LO_LO_LIM 2 43 FLOAT S 4 R/W
30 HI_HI_ALM 2 46 DS-39 D 16 R
31 HI_ALM 2 47 DS-39 D 16 R
32 LO_ALM 2 48 DS-39 D 16 R
33 LO_LO_ALM 2 49 DS-39 D 16 R
34 SIMULATE 2 50 DS50 S 6 R/W
35 OUT_UNIT_TEXT 2 51 OCTETSTRING S 16 R/W
