8039 9
ENGLISH ENGLISH
Protection against
polarity reversal
yes
Transistor output NPN and/or PNP, open collector, max. 700 mA, NPN output: 0,2-30 VDC and PNP output:
supply voltage (see example in the Annex)
Relay output 250 VAC, max. 3 A or 30 VDC, max. 3 A; programmable
Frequency output NPN transistor, open collector, max. 700 mA, 0,2-30 VDC, not programmable
Protection against
short-circuits
yes for the transistor output
Type of cable recommended shielded, wire section between 0.14 and 0.5 mm 2
electrical connection
NPN version EN 175301-803 cable plug (supplied)**
PNP version EN 175301-803- (supplied)** or 5-pin M12 (not supplied) cable plug
NPN/PNP version 5-pin M12 cable plug (not supplied)
Relay (+ frequency) version EN 175301-803 (supplied)** and 5-pin M12 (not supplied) cable plugs
** EaseOn with cable plug type 2511 on request
materials
Housing polycarbonate, fiber glass reinforced
Front plate polyester and polycarbonate
Fitting S039 brass
Sensor holder / paddle-wheel PVDF
Fitting axis / bearings ceramic
O-rings FKM standard (EPDM as an option)
environment
Ambient temperature 0 to +60 °C
Relative humidity < 80%, non condensated
