flow rate controller 8039
1
3
2
4
5
3
1 2
0 VDC
V+
(12-30 VDC)
4.3. Version with pnp transistor output via m12 connector
4.3.6 Version with relay output
Sensor Receiver
Load
PNP
output
pnp output
PNP transistor output
Not connected
pnp wiring of m12 fixed
connector
relay output
wiring of fixed
connector
en 175301-803
Common
Not connected
Normally Closed
Normally Open
Not connected
Not connected
(*)
(*)
4 installation
PNP
0 V
V+ V+
IN
0 V
(*)
4
5
3
1 2
0 VDC
V+
(12-30 VDC)
pin number of the m12 cable available as
an accessory (order code 438680)
Wire colour
1 brown
2 white
3 blue
4 black
5 grey
The controller is fitted with a steerable M12 fixed
connector:
Unfasten counternut. Turn the fixed connector to the
right position, but by max. 360° to avoid twisting of the
cables inside the housing. Fasten counternut using the
appropriate tool while maintening the fixed connector in
the right position.
Wiring of fixed connector m12 (12-30 Vdc power supply)
