17
Dosingsystem(Optional)
panel "Bistable valves" / "Monostable valves"
The settings refer to optional hardware features. Further
information on request.
Ok Save settings and close window
Cancel Leaving window without changes
load
Loads the device configuration from the
configuration file
save Saves the device configuration (including the tuning
parameters) in the configuration file.
Window "pump tuning" 9.3.3.
Seven time parameters are entered here T0...T6 [ms] for the control
of the dosing units; the frequency is determined by the pause.
pump tuning
Ok
Save settings and close window
Cancel Leaving window without changes
defaults
Sets the time parameters back to the default
settings
See also the control diagram in chapter „Start-up /
Functions“
english
Type 7616
