3-23
Section 3 Operation
BM Oval Series
Installation and Operation Manual
X-PD-BM-Ovals-eng
Part Number: 541B031AAG
January, 2009
PRESIGNAL
Calibration Constant 01 to 10 Filling Quantity 01 to 10
Location No. Location No. Location No. Location No.
01 06 01 06
02 07 02 07
03 08 03 08
04 09 04 09
05 10 05 10
Location No. Location No.
Table 3-4 Summary Table for Normal Operation
Table 3-5 Summary Table for Automatic Operation
Figure 3-22 Example Application #3.
Necessary Cable Connections:
A. Pulse cable from LC-Display to quick action tap (Max. 12m).
B. Control Cable from quick action tap to amplifier.
C. Supply voltage cable from amplifier to valve.
Summary Tables:
If the battery has not been removed within one minute, all registered
constants will be reset to 0500.
Factory Calibration on location with calibration fluid M4=0089, M10=0178, M40=0689, M50=1500
01 06
02 07
03 08
04 09
05 10
Factory Set (See Above)
