Page 16
1-8
Section 1 Introduction
Installation and Operation Manual
X-PD-BM-Ovals-eng
Part Number: 541B031AAG
January, 2009
BM Oval Series
Table 1-7 Optional Accessories
Table 1-8 Higher Viscosity Coefficient Factors
Table 1-6 Recommended Strainer Sizes
1-5 Accessories and Options
(Refer to Table 1-7)
• Standard LCD Display • High Viscosity Rotors (gears)
• Deluxe LCD Display
• High Temperature Rotors (gears)
• Mechanical Register
• Heating Jacket
• Recommended Strainer Sizes,
(Refer to table 1-6)
Strainer Recommendations
Model
Max Partical Size
Strainer Size
BM04
0.011" (0.28mm)
60 Mesh
BM07
0.011" (0.28mm)
60 Mesh
BM10
0.011" (0.28mm)
60 Mesh
BM40
0.015" (0.38mm)
60 Mesh
BM50
0.018" (0.46mm)
60 Mesh
Models
Coefficient
Viscosity
BM04
BM07
BM10
BM40
BM50
Factors
GPM
LPM
GPM
LPM
GPM
LPM
GPM
LPM
GPM
LPM
1
< 2500 cP
9.3
35.0
21.1
80.0
31.7
120.0
66.1
250.0
92.5
350.0
0.9
< 3000 cP
8.3
31.5
19.0
72.0
28.5
108.0
59.5
225.0
83.2
315.0
0.8
< 4000 cP
7.4
28.0
16.9
64.0
25.4
98.0
52.8
200.0
74.0
280.0
0.7
< 5000 cP
6.5
24.5
14.8
56.0
22.2
84.0
46.2
175.0
64.7
245.0
0.6
< 8000 cP
5.6
21.0
11.8
48.0
19.0
72.0
39.6
150.0
55.5
210.0
0.5
< 12000 cP
4.6
17.5
10.6
40.0
15.9
60.0
33.0
125.0
46.2
175.0
0.4
< 25000 cP
3.7
14.0
8.5
32.0
12.7
48.0
26.4
100.0
37.0
140.0
0.3
< 40000 cP
2.8
10.5
6.3
24.0
9.5
36.0
19.8
75.0
27.4
105.0
0.2
< 95000 cP
1.9
7.0
4.2
16.0
6.3
24.0
13.2
50.0
18.5
70.0
0.1
< 450000 cP
0.9
3.5
2.1
8.0
3.2
12.0
6.6
25.0
9.3
35.0
0.05
< 1000000 cP
0.5
1.8
1.1
4.0
1.6
6.0
3.3
12.5
4.6
17.5
Optional Accessories
Available on
Standard LCD
Deluxe LCD
Mechanical High Viscosity
High Temp
Models
Display
Display
Register
Rotors (Gears) Rotors (Gears)
BM04
Yes
Yes
Yes
PPS or 316 SS
PPS
BM07
Yes
Yes
N/A
PPS Only
N/A
BM10
Yes
Yes
Yes
PPS or 316 SS
PPS
BM40
Yes
Yes
Yes
PPS or 316 SS
PPS
BM50
Yes
Yes
Yes
PPS or 316 SS
PPS
