Section 1 Introduction
Installation and Operation Manual
X-PD-BM-Ovals-eng
Part Number: 541B031AAG
January, 2009
BM Oval Series
Table 1-10 Weights
Table 1-9 Model Codes
Body Material
Model
Connection
Alum
PPS
316 SS
BM04
Screwed
3 lbs (1.4 kg)
N/A
6 lbs (2.7 kg)
BM07
Screwed
N/A
3 lbs (1.4kg)
N/A
BM10
Screwed
6 lbs (2.7 kg)
N/A
10 lbs (4.6 kg)
BM10
Flanged
10 lbs (4.6kg)
N/A
14 lbs (6.3 kg)
BM40
Screwed
11 lbs (5 kg)
N/A
19 lbs (8.6 kg)
BM40
Flanged
13 lbs (5.9 kg)
N/A
21 lbs (9.6 kg)
BM50
Flanged
16 lbs 7.3 kg)
N/A
42 lbs (19.1 kg)
MODEL BASIC MODEL
BM
BROOKS-OVAL
CODE
NOMINAL SIZE
04
1/2 INCH
07
1 INCH
10
1 INCH
40
1/12 INCH
50
2 INCH
CODE
REVISION
A
CURRENT REVISION
CODE
BODY MATERIAL
A
ALUMINUM
B
BRONZE (BM10 METER ONLY)
R
PPS (BM7 METER ONLY)
S
316 STAINLESS STEEL
CODE
ROTOR/GEAR MATERIAL
R PPS
ROTOR
(GEAR) SET
S
316 STAINLESS STEEL ROTOR (GEAR) SET
CODE
PULSER/DISPLAY
P
PULSE OUTPUT
E
DELUXE LCD DISPLAY (PROGRAMMABLE, GALLONS OR LITERS)
F
STANDARD LCD DISPLAY, (PROGRAMMABLE, GALLONS OR LITERS)
M
MECHANICAL REGISTER, GALLONS, REGISTRATION
N
MECHANICAL REGISTER, LITERS REGISTRATION
CODE
CONNECTION
AVAILABLE ON METER MODEL/SIZES
TYPE
BM04
BM07
BM10
BM40
BM50
2
NPT
YES
YES
YES
YES
YES
4
150 # RF
N/A
N/A
YES
YES
YES
5
DIN 16
N/A
N/A
N/A
YES
N/A
7
TRICLOVER
N/A
N/A
YES
N/A
N/A
8
300 # RF
N/A
N/A
N/A
YES
N/A
CODE
OUTPUT/ELECTRONIC
R
REED SWITCH (STANDARD)
H
HALL EFFECT (OPTIONAL)
N NONE
(MECHANICAL REGISTER OPTION)
CODE
VISCOSITY
1
STANDARD <1000 CP (ALL ROTOR (GEAR) MATERIALS)
2
HIGH > 1000 CP, PPS ROTORS (GEARS)
3
HIGH > 1000 CP, STAINLESS STEEL ROTOR (GEARS)
CODE
TEMPERATURE CLASS
A
STANDARD TEMP. PPS ROTORS (GEARS), 80C / 176F
B
HIGH TEMP. PPS ROTORS (GEARS), 120C / 248F
C
STANDARD TEMP. SS ROTORS (GEARS) 120C / 248F
CODE
SEALS/O-RINGS
V
VITON
K
TEFLON
CODE
OPTIONS
A
NONE (STANDARD METERS)
C
HASTALLOY C SHAFTS, BM07 METER ONLY.
S
SOLVENT KIT, ALUM MECH METERS
CODE
APPROVALS/CERTIFICATIONS
A
NONE
BM
10
A
A
R
P
2
R
1
A
V
A
A
