1-3
Section 1 Introduction Installation and Operation Manual
X-PD-BM-Ovals-eng
Part Number: 541B031AAG
January, 2009
BM Oval Series
(Refer to Table 1-3, below)
Nominal K-Factor for both Reed and Hall effect switch:
Table 1-4 Materials of Construction
Electrical Connections
Pulser cap: 1/2" NPT
Dimensions
(Refer to Figure 1-1, on next page)
For certified dimensional prints, contact the factory.
For weights (Refer to Table 1-10)
Table 1-5 Connections
Table 1-3 K-Factors
K-Factors/Pulse Output Resolution
Gallons Liters
Model Single Switch Dual Switch Single Switch Dual Switch
BM04 424.3 848.6 112 224
BM07 197 394 52 104
BM10 136.3 272.6 36 72
BM40 54.9 109.8 14.5 29
BM50 25.29 50.58 6.68 13.36
Item Materials Meter Model/Size
BM04 BM07 BM10 BM40 BM50
Body PPS N/A Standard N/A N/A N/A
Aluminum Standard N/A Standard Standard Standard
316 Stainless Stl. Standard N/A Standard Standard Standard
Bronze N/A N/A Option N/A N/A
Rotor/Gear PPS Standard Standard Standard Standard Standard
316 Stainless Stl. Option N/A Option Option Option
Shaft- 316 Stainless Stl. Standard Standard Standard Standard Standard
Rotor/Gear Hastelloy C N/A Option N/A N/A N/A
Cap- Aluminum Standard N/A Standard Standard Standard
Pulse Meter 316 Stainless Stl. Option N/A Option Option Option
PPS N/A Standard N/A N/A N/A
O-Ring- Viton ® Standard Standard Standard Standard Standard
Body Teflon ® Option Option Option Option Option
O-Ring/Seal Viton N/A N/A Option Option Option
Mech. Register
BM04 1/2 inch NPT
BM07 1 inch NPT
BM10 1 inch NPT
1 inch 150 Lb RF Flange
1 inch TriClover
BM40 1 1/2 inch NPT
1 1/2 inch 150 Lb RF Flange
1 1/2 inch 300 Lb RF Flange
BM50 2 inch NPT
2 inch 150 Lb RF Flange
