2-2
Section 2 Installation
Installation and Operation Manual
X-PD-BM-Ovals-eng
Part Number: 541B031AAG
January, 2009
BM Oval Series
2-4 Return Shipment
Prior to returning any instrument to the factory visit the Brooks website
www.BrooksInstrument.com for a Return Materials Authorization Number
(RMA#), or contact one of the following locations:
Brooks Instrument
407 W. Vine Street
P.O. Box 903
Hatfield, PA 19440 USA
Toll Free (888) 554-FLOW (3569)
Tel (215) 362-3700
Fax (215) 362-3745
E-mail: [email protected]
www.BrooksInstrument.com
Brooks Instrument Brooks Instrument
Neonstraat 3 1-4-4 Kitasuna Koto-Ku
6718 WX Ede, Netherlands Tokyo, 136-0073 Japan
P.O. Box 428 Tel 011-81-3-5633-7100
6710 BK Ede, Netherlands Fax 011-81-3-5633-7101
Tel 31-318-549-300 Email: [email protected]
Fax 31-318-549-309
E-mail: [email protected]
Instrument must have been purged in accordance with the following:
All flow instruments returned to Brooks requires completion of Form
RPR003-1, Brooks Instrument Decontamination Statement, along with a
Material Safety Data Sheet (MSDS) for the fluid(s) used in the instrument.
Failure to provide this information will delay processing by Brooks
personnel. Copies of these forms can be downloaded from the Brooks
website www.BrooksInstrument.com or are available from any Brooks
Instrument location listed above.
2-5 Transit Precautions
To safeguard against damage during transit, transport the meter to the
installation site in the same container used for transportation from the
factory if circumstances permit.
Vertical Installation Horizontal Installation Do Not Install Meter This Way
Note: Rotor shafts must always be parallel to the ground
Figures 2-1 Proper Orientation of Meter Assembly.
