Operation Manual ELI-EPTZ-27DN eLineTechnology.com
19
[3]. Move the joystick left/right or press OPEN to enter the Limit Operation.
.Start Position
⑵ . End Position
Refer to Start Position setting section.
.Direction
Move the joystick left/right to select the Direction(left or right).
.Operation
Select the OPERATION and move the joystick left/right set up the Operation of
POWER ON ACTION
1 ACTION VECTORSCAN
2 NUMBER 1
[2].Select the Power on Action and
move the joystick left/right or press
OPEN to enter the Power on Action.
. Select the Action and move the joystick left/right or press OPEN to enter Action.
Actionincludes:None/Preset/VectorScan/Pattern/PanScan/AutoScan
.Select the Number and move the joystick left/right or press OPEN to enter. Setup
method: refer to preset setup instruction.
Move the joystick
left/right or press OPEN
IRIS OPEN WHEN DONE
LIMIT OPERATION
1 START POSITION 0.0
2 END POSITION 0.0
3 DIRECTION RIGHT
4 OPERATION OFF
