2.7.5 Mask Zone

Function: User can protect the partial area by mask setting from the whole monitoring

area according to the situation.

[2].Pan Start POS \Pan End POS\Tilt Start POS\ Tilt End POS

.Move the joystick left/right or press OPEN to select a Pan Start Point \Pan End

Point\ Tilt Start Point\ Tilt End Point.

⑵

.IRIS OPEN when done or press CLOSE to exit, but not save.

[3].Name

⑴

.Select the sector name and press OPEN to enter name editing.

⑵

.Edit the name referring to preset setup instruction.

[4].Name Display

Joystick Up/Down to move the cursor to select Name Display of ON or OFF.

MASK ZONE

1 NUMBER 1

2 MASK EDIT

3 MASK DISPLAY OFF

MASK ZONE

[1].Number

.Joystick Up/Down to move the cursor to

select NUMBER.

⑵.

Joystick Left/Right to select pending

editing mask areas(from area1-24).

[2].Mask Edit

.Joystick Up/Down to move the cursor to select Mask Zone.

⑵

.Joystick Left/Right or press OPEN to enter editing.

⑶

.Press OPEN to edit the mask zone, capture the mask point. Press NEAR,

FAR (set the mask area in pan action), WIDE, TELE (set the mask area in

tilt action) to adjust the area of mask zone. Press CLOSE to exit when done

and return to upper stage menu.

[3].Mask Display

Joystick Left/Right to set up the display name of ON/OFF.
