2.7.2 Program VectorScan
Function: User can make different auto scan according to various inspection.
Programming VectorScan instruction
[1].Joystick Up/Down to select Program
VectorScan.
[2].Joystick Left/Right or press OPEN to
enter the programming.
[3].Joystick Up/Down to select pending
programming serial number(number
range:1～6).
[4].Move the Joystick to select and enter
the items of Program a VectorScan
(items include:name/number/SP/dwell).
I :Name
Pr:stands for Preset Position.
Vs:stands for VectorScan.
Pt: stands for PTZ Tour.
II :Number Programming-selection
based on the name.
III :SP-Set up the speed of Preset.
IV :Dwell
Vectorscan running operation steps:
I :Select pending Vectorscan track in
Number menu
II :Joystick Up/Down to select Vectorscan
III :Joystick Left/Right or press OPEN to
run the selected Vectorscan track
FUNCTION PROGRAMMING
1 PRESET
2 VECTORSCAN
3 PATTERN
4 SECTOR SETUP
5 MASK ZONE
6 MASK COLOR
7 MOTION
VECTORSCAN
1 NUMBER 1
2 PROGRAM A VECTORSCAN
3 RUN A VECTORSCAN
4 DELETE A VECTORSCAN
PROGRAM VECTORSCAN 1
NAME NUM SP DWELL
1.
2.
3.
4.
... ...
16.
IRIS CLOSE WHEN DONE
DELETE A VECTORSCAN
Vectorscan track deletion steps:
[1]:Select pending deleting vectorscan track in Number menu.
[2]:Joystick Up/Down to select Delete a VectorScan.
[3]:Joystick Left/Right or press OPEN to delete the selected vectorscan track.
