Datamax-O'Neil S-Class SV Cutter Option User Manual
Page 9
7
6. Install the Cutter CCA (Item 2) into the printer by placing the Tab into the Locator Hole in the
Baseplate.
Cutter CCA
Tab
Baseplate
Locator Hole
7. Insert the Screw (Item 6) into the Washer (Item 7), and then securely fasten the Cutter CCA to the
Baseplate using the Screw and Washer.
Screw
Washer
Cutter CCA
Baseplate
