The Pulse LE [TAKE] button allows to switch from Preview to Main
outputs. By pressing the [TAKE] button, what you have setup on
your preview screen will go live on the Main output display.
The Pulse LE [EFFECT] selection button is a practical front panel
shortcut to the Pulse LE Layer Effects menu (Opening and Closing
transitions).
The Pulse LE [PRESET] selection button is a practical front panel
shortcut to the Pulse LE Preset menu, and will activate the four
available Preset Memories (Input Selection section buttons #1 to
#4).
The PIP button of the Pulse LE allows users to freeze the Main
output current display or the active layer, depending on the freeze
mode: Freeze All, freezes all visible layers, Layer Freeze, to freeze
the current selected layer.
The Pulse LE [BACKGROUND LIVE] button will allow you to
select the source you wish to use as a live background, and will
automatically display the Layer menu on your VFD screen.
PIP button
Take button
Effect selection button
Preset selection button
Bacground Live button
