The STANDBY button allows users to put the Pulse LE into sleep
mode, and startup again. The STANDBY button does not replace
the ON/OFF switch at the rear of the unit, and is implemented
essentially for ease of use in rackmount situations.
The Menu Screen of the Pulse LE is the visual interface to your
Pulse LE menu. It gives users a constant indication of available menu
options, parameters of any selected object, system information, and
everything you need to know to control the device.
The Menu scroll knob allows users to quickly scroll through menu
items and increase or decrease any modifiable value in the Pulse LE
menu. Simply scroll to the desired menu item, and press the ENTER
button to confirm your choice.
The EXIT/MENU button and the ENTER button in the Control
section of the Pulse LE, allow users to respectively enter and exit
the Pulse LE menu, and confirm selected menu items.
The Input Selection section allows to select which input (#1 to #10)
to display in a selected layer. Select one of 10 simultaneous inputs,
(6 analog inputs, 2 DVI-D inputs, 2 SDI inputs) by simply pressing
one of the Input buttons.
When pressed, the BLACK button allows users to remove layer
content on screen.
The Freeze button of the Pulse LE allows users to freeze the Main
output current display or the active layer, depending on the freeze
mode : Freeze All, freezes all visible layers, Layer Freeze, to freeze
the current selected layer.
Standby button
Menu section
Input selection section
Freeze button
25
