Page 20

The

Pulse LE can be set up with up to 10 different sources, and will drive up to 2 digital DVI-D sources, 2 SD-

SDI sources and 6 analog computer/video sources simultaneously. The versatility of the

Pulse LE will allow

for almost any event configuration and cater for all your projection needs.

The intuitive rear panel of the

Pulse LE will let you set up for the first time quickly and easily.

Here is an example of a typical

Pulse LE setup.

3-1. CONNECTING THE PLS200

CONNECTING THE PLS200
