Operating the pls200 – Analog Way Pulse LE User Manual
Page 25

The highly intuitive front panel of the
Pulse LE was designed by Analog Way engineers to simply and quickly
meet all of your event needs. Within minutes, you will be able to enjoy its full potential and easily parameter
most of its functions, without having to be an expert audio-visual engineer, leaving room for what is most
important to our users: concentrating on their event.
The
Pulse LE front panel is comprised of several sections, each carefully labeled and self explanatory,
corresponding to all the machine’s versatile functions.
1 : Standby button
2 : Menu screen
3 : Menu Control section
4 : Menu scroll knob
5 : Input Selection section
6 : Preset button
7 : PIP button
8 : Freeze button
9 : Background Live button
10 : Effect button
11 : Take button
OPERATING THE PLS200
4-1. THE PLS200 FRONT PANEL
Overview
24
4
5
6 7
1
2
3
8 9 10
11
