Installation Instructions PXR
7
TOOLS REQUIRED FOR INSTALLATION
PARTS
7/32" (5.5mm) - wood
#2
1/2" (12.7mm)
M5
5/16" (8.0mm) - concrete
9" Hex
(included)
3/16"
(included)
+ + _
V
Q (1)
[PXR]
X (1)
[Mounting Bracket]
RA (4)
5/16"
RC (4)
5/16" x 2-1/2"
S (2)
08-32 x 1/4"
U (4)
1/4-20 x 1/2"
A (8)
(M4 x 16mm) B (6)
M4 x 20mm C (6)
M4 x 25mm
D (6)
M5 x 16mm E (6)
M5 x 20mm F (6)
M5 x 25mm
G (6)
M6 x 16mm H (6)
M6 x 25mm
I (6)
M8 x 20mm J (6)
M8 x 30mm
K (4)
M8 x 50mm
L (8)
.750 x .323 x .250
M (8)
.750 x .344 x .500
NA (8)
NB (1)
M5 RB (4)
5/16"
[Power Cord]
Z (1)
V (2)
[Interface Bracket]
BB (1)
[Remote Control with
T (2)
8-32 x 3/8"
Y (1)
9" Hex
P (2)
[Plastic Cover]
W (2)
[Bracket Lock]
[IR Receiver with
AA (1)
Velcro® disc]
CC (4)
5/16-18 x 5/8"
DD (4)
1/4"
FF (1)
3/16"
EE (4)
5/16"
two AAA batteries]
