I 0645 11 GB
2.1 - How to interact with the program
The operations indicated by the on-screen keys F1 ... F7 can be performed by clicking on or pressing ...
on the keyboard or pressing the arrow buttons of the measuring head keypad.
On the normal pages (image on the left)
... : the function of these keys varies from page to page
or : goes back to the previous page
or : goes to the next page
: Help
: goes back to the home page
In the menus (image on the right)
... : Select the desired function
: Exits from the menu
To sa • ve time and avoid moving between the vehicle and the cabinet you can move between
the pages using the measuring head keypad.
To continue with the alignment procedure press • or
