8
Tighten Rear Endcap
Install J-Bolts
Pull the Tightening Lip tight against the opposite
auger side of the grain cart. Using a 1/4” bit, drill
through the hole on the top of the endcap. Fasten the
endcap by using an 1/4” x 1-1/2” bolt and nut. Tight-
en the bolt. Now go to the other end of the endcap
and do the same procedure.
Now place (3) 3/8” j-bolts into the three remaining holes in the rear endcap. Fasten the j-bolts with
(3) 3/8” locknuts. Do not tighten past flush.
Tools Needed:
1/4” Drill Bit
7/16” Wrench & Socket
