J&M Roll Tarp GRAIN CARTS (June 2011 & newer) User Manual
Page 10
10
Install Cable Clamps
Cable Clamp Assembly
Using the three cable clamp, feed one end of the cable through the cable clamp, make a small loop then tighten
the cable. Do this with all three cables.
Now route all three cables through the front endcap pulling the end without the cable clamps through first.
Make sure to pull from front to back. Next route the cables over the arched bows and thread them through
the existing holes on the rear endcap. Now feed the cables through the cable clamps, make a small loop into
the j-bolt. Use a visegrip to pull on the cable. Pull the cable tight, then tighten the cable clamp. Once the
clamps are tightened, tighten the the j-bolts. Insert a wrench into the hook of the j-bolt and tighten the nut.
Tools Needed:
7/16” Socket or Wrench
Tools Needed:
7/16” Wrench or Socket
9/16” Wrench or Socket
Screwdriver
Use screwdriver or bolt to hold the j-bolt while tightening.
