J&M Roll Tarp GRAIN CARTS (June 2011 & newer) User Manual
Page 17
17
PARTS LIST
1130 Leaner
1150
1250 Leaner
1325/1400 1500 Leaner
Tarp Crank Handle
XL
XL
XL
XL
XL
Square Tubing (1" x 1" Sq.
Tube) 14 Gauge
264"
264"
264"
306"
306"
Roll Tube (1.25" x 1.25" Sq.
Tube) 11 Gauge
270"
270"
270"
312"
312"
Drip Edge
99"Front 165" Back 132"x2
99"Front 165" Back 153"x2
153"x2
Front Endcap
46.187" & 119.187" 141.25"
46.187" & 119.187" 141.25"
46.187" & 119.187"
Back Endcap
46.187" 119.187"
141.25"
46.187" 119.187"
141.25"
46.187" 119.187"
Front End Plate
48.5" & 118.875"
140.5"
48.5" & 118.875"
140.5"
48.5" & 118.875"
Back Endplate
46.25" & 117"
137.25"
46.25" & 117"
137.25"
46.25" & 117"
Tarp Bows
161.75" x 7
137.5" x 7 161.75" x 7
137.5" x 7
161.75" x 8
Ridge Cable (3 Per) (4 per
Leaner)
264"
264"
264"
306"
306"
Canvas Tarp
1130
1050
1250
1325
1500
Nylon Strip
1
1
1
1
1
Stop Bracket
3
3
3
3
3
Prop Up Bar - Upper (2 Per) 27"
27"
27"
27"
27"
Prop Up Bar - Lower (2 Per) 13"
13"
13"
13"
13"
Plastic Standoffs
2
2
2
2
2
J-Bolt Small
4
3
4
3
4
Hanger Bracket
29"
29"
29"
29"
29"
Hanger Bracket Hook
1
1
1
1
1
1/4" Flange Nuts
100
74
100
74
104
1/4" x 1/2" SF Bolt
45
33
45
33
45
1/4" x 5/8" SF Bolt
19
5
19
5
19
1/4" Locknut
1
1
1
1
1
1/4" x 2-1/2" Bolt
1
1
1
1
1
1/4" x 3/4" Bolt
28
36
32
36
40
3/8" SF Nuts
13
13
13
13
13
3/8" x 1" SF Bolts
10
10
10
10
10
3/8" x 2" Bolts
5
5
5
5
5
3/8" Locknuts
4
3
4
3
4
1/2" Locknuts
1
1
1
1
1
1/2" x 1-1/4" Bolts
1
1
1
1
1
3/16" Cable Clamp
8
6
8
6
8
Universal Joint
1
1
1
1
1
1/4" Drive Rivet
10
10
10
10
10
1/4" x 1-1/2" STS
14
14
14
14
14
Yellow Rubber Cap
1
1
1
1
1
Rubber Flap
1
1
1
1
1
GrainCart Spring Return
(95" Long)
1
1
1
1
1
