TG29D

Section A: Wiring Diagrams

CEN N1601, N1602, N1603, N1604

Alternator and Regulator Description

and Operation

The alternators listed below are self-rectifying. All wind-

ings and current-transmitting components are non-

moving, so there are no brushes or slip rings to wear

out. Energize switch activates regulator. Field coil is

then energized.
• N1601

28 V 400 A

N1602 28 V 400 A with optional 28 V/ 14 V

(50 A maximum on 14 V)

• N1603

28 V 450 A

N1604 28 V 400 A

N3107 regulator used on some N1601, N1603, and

N1604 alternators maintains alternator output voltage

at regulated setting as vehicle electrical loads are

switched on and off. Alternator output current is self-

limiting and will not exceed rated capacity of alternator.

The regulator has:
• an AC terminal to provide optional AC voltage

output tap.

• overvoltage cutout (OVCO). Regulators with OVCO

(overvoltage cutout) will trip at vehicle electrical

system voltages

above 32 volts that exist longer than

3 seconds. OVCO feature detects high voltage and

reacts by signaling relay in field control circuit to

open. This turns off alternator. Restarting engine

resets OVCO circuit.

The following regulators receive energize signal after

engine is running:
• N3118—used on some N1602 alternators

N3211—used on some N1601 and N1603 alternators

N3223—used on some N1602 alternators

N3236—used on some N1604 alternators

N3237—used on some N1602 and N1603 alternators

N3245—used on some N1602 and N1603 alternators

Regulator monitors alternator rotation and provides

field current only when it detects alternator shaft rotat-

ing at suitable speed. After regulator detects alternator

rotation, it gradually applies field current, preventing an

abrupt mechanical load on accessory drive system. The

soft start may take up to 10 seconds at full electrical

load. These regulators:
• are negative temperature compensated. Setpoints

are 28.0 ± 0.2 V (and on N3118 and N3223, 14.0 ±

0.2 V. See below.) at 75F. N3237 and N3245 regula-

tors are negative temperature compensated accord-

ing to switch-selected battery type. Customer selects

position per application.

• provide overvoltage cutout (OVCO). Regulator will

trip OVCO when system voltage rises above 32 V in

a 28 V system (16 V in a 14 V system) for longer than

3 seconds. OVCO feature detects high voltage and

signals the field circuit to open, turning off alterna-

tor. Restarting engine resets OVCO circuit.

• maintain alternator output voltage at regulated

settings as vehicle electrical loads are switched

on and off.

N3118 and N3223 regulators can be used in single

28 V or dual voltage applications. The regulators:
• allow single-voltage operation (28 V only). 14 V

single voltage application is not available with

these regulators.

• provide optional 28 V/14 V output only from the

regulator when phase cable from alternator is

connected to regulator.
