Yes No
With engine off, is battery voltage present at alternator 14 V B+ terminal?
Chart 5 – A2-303 Regulator – No 14 V Alternator Output – Test Circuit
Yes No
Connect DMM red lead to pin E on alternator-to-regulator harness plug.
Connect black lead to pin C on same plug.
Does battery voltage exist? See Figure 9, page 9.
Alternator is defective.
T
Repair vehicle wiring as necessary.
Continue test.
T
T
T
Substitute a known good regulator. Run engine. Is regulator setpoint voltage present?
Yes No
Original regulator was defective.
T
Alternator is defective.
T T
(CONT’D)
