The FUEL - Main Table calibration screen is shown below, the other adjust
screens are similar. Not all the calibration data can be seen at once, if the
adjustment cursor is moved to the edges of the table the table will scroll.
Table Name
Table Units
Load Indicator
Target
Cursor
Number of Diagnostic Errors
RPM Indictor
Sensor Readings
The calibration screens show basic sensor readings at the top of the screen,
including RPM, Load Point, Throttle Position etc. The number of Diagnostic
Errors is also shown, which should normally be zero. More detailed
information may be shown by displaying the View screen (Press the V key).
Selecting the Site to be Adjusted
The cursor shows which table value may be adjusted.
The cursor may be moved using the arrow keys, or by pressing the SPACE
BAR which will automatically move the cursor to the current engine operating
point.
