30 Initial Setup
SYSn Sync Sensor Type (M4 & M48 only)
rEF
Ref / Sync Mode
crt Crank Reference Teeth
criP Crank Index Position
These parameters are dependant on the type of trigger system. Refer to the
appropriate MoTeC Trigger drawing, or Ignition System drawing.
Ignition
ign Ignition System Type
COIL Number of Coils
dELL Ignition Dwell Time
dLY
Ignition System Delay
These parameters are dependant on the type of Ignition Module. Refer to the
appropriate MoTeC Ignition Module drawing, or Ignition System drawing.
Miscellaneous Setup
All parameters must be set appropriately. (Advanced Tuning only)
Refer to the E.M.P. help screens for details.
Sensor Setup
Throttle Position Sensor Hi / Lo
TPLO Throttle Position LO (Closed Throttle)
TPHI Throttle Position HI (Wide Open Throttle)
The Throttle HI and LO points must be set every time the throttle position
sensor is moved or replaced so that the throttle can be correctly scaled
between 0 and 100%.
Sensor Selections
The Air Temp, Engine Temp, MAP and other sensor types must be selected
in the sensor setup.
Any unused sensor inputs should be turned off.
Refer to the E.M.P. help screens for details.
