MoTeC Appendices 31
Appendix B – BTX Specifications
BTX (Beacon Transmitter)
Mating Connector
Connector: Hirschman CM06EA14S-7S
Electrical
Operating Voltage Range: 10.5V to 16V
Operating Current: 70mA typical
Environmental
Operating Temperature Range: -10C to 85 °C Internal
Battery
An external battery is required.
Recommend Battery Type: Sealed lead acid
Recommended Capacity: 10Ahr or greater (approx 4 days operation)
Alignment
Within 5 degrees of optimum (preferably 2 degrees).
Minimum Spacing
The distance between adjacent transmitters must be greater than 6m (20ft)
