72
In the Brake cable replacement screen, the tool can perform
three functions.
A. Put in fitting or removal position
This function enables you to fit in or remove the brake cable
safely and easily. It will take a few seconds to execute this
command.
Figure 8.6
When the job is done successfully, the tool will display a
message to confirm.
Figure 8.7
If the job fails to finish, the tool will display a message to remind
user of a problem. After you exit the diagnosis program, please
repair the problem immediately.
Put in fitting/removal position
Activation in progress!
OK
Put in fitting/removal position
Positioning done.
To replace or remove the brake
cables, refer to the mechanical
schedule "Removal-replacement:
electric parking brake primary and
secondary cables"
Press any key to continue
OK
